HFCG SERIES ROLLER PRESS

Date:2021-02-25 09:50 Number: Size:[ Big ] [ Middle ] [ Small ]



   Introduction   
HFCG Series of Roller Press is high efficiency energy saving grinding equipment which has developed by Hefei Research & Design Institute [CNBM(Hefei) Powder Technology Equipment Co.,Ltd.] with independent intellectual property right. These research and development projects such as "Roller Press Grinding New Process and Equipment" and " Roller Press Grinding Technology and Equipment For Energy Conservation" has provided better solutions for grinding powder in the mining, building materials industry, and they were rewarded silver medals respectively at the state level and at the sector level. The grinding system with HFCG roller press is adopted, of which main technical and economic indicators such as power consumption and physical features have reached the international advanced level at nowadays. The total sales of HFCG roller press has reached 1600 sets, ranking first in the world.


   Characteristics  
  • The advanced structure of roller sleeve and the process of roller surface wear resistance could make the service life of roller surface between 8000 and 30000hrs.
  • The hydraulic system could operate more reliable with the design of flexible constant pressure and unique structure.
  • Roller press runs more stably with a compact torque supporting unit.
  • The advanced detection and automation control system ensure a safe and smooth running of roller press.

Cement Industry--Roller Press (HFCG)


 Series


Model

 Diameter of roller(mm)

Width of roller(mm)

Motor Power(kW)

Feeding size(mm)

Throughput (t/h)

120 Series

HFCG120-45

1200

450

2*200

50

125~150

HFCG120-50

1200

500

2*250

50

140~165

HFCG120-80

1200

800

2*250

25

85~100

140 Series

HFCG140-65

1400

650

2*500

60

240~295

HFCG140-70

1400

700

2*500

60

260~315

HFCG140-80

1400

800

2*500

60

295~360

150 Series

HFCG150-100

1500

1000

2*710

60

415~500

160 Series

HFCG160-120

1600

1200

2*900

70

580~670

HFCG160-140

1600

1400

2*1120

70

680~780

180 Series

HFCG180-160

1800

1600

2*1600

70

950~1100

200 Series

HFCG200-180

2000

1800

2*2000

70

1450~1700


Mining Industry--Roller Press (HFKG)

Series

Model

Diameter of roller(mm)

Width of roller(mm)

Installed Power Max,kW)

Feeding size(mm)

Throughput (t/h)

140 Series

HFKG140-50

1400

500

2*400

30

360

150 Series

HFKG150-60

1500

600

2*500

30

470

HFKG150-80

1500

800

2*630

30

620

160 Series

HFKG160-100

1600

1000

2*900

30

830

HFKG160-120

1600

1200

2*1120

35

1000

HFKG160-140

1600

1400

2*1250

35

1170

180 Series

HFKG180-100

1800

1000

2*1000

35

940

HFKG180-120

1800

1200

2*1250

35

1120

HFKG180-140

1800

1400

2*1400

35

1300

200 Series

HFKG200-120

2000

1200

2*1600

40

1420

HFKG200-160

2000

1600

2*2000

40

1900

220 Series

HFKG220-160

2200

1600

2*2240

40

2100

240 Series

HFKG240-180

2400

1800

2*3150

40

2660

Notes:
1. Product Size could satisfy the requirements which is in the range 0.045mm to 3mm.
2. The above two tables only include a part of models for reference, we also provide many other specification equipments which could be used in nonferrous metallurgy and industrial waste. Please contact us for more information.
